2 F MC-16 FAMILY TM SOFTUNE Workbench USER'S MANUAL FUJITSU SEMICONDUCTOR LIMITED

Summary of the content on the page No. 4

Summary of the content on the page No. 5

PREFACE ■ What is the SOFTUNE Workbench? 2 SOFTUNE Workbench is support software for developing programs for the F MC-16 family of microprocessors / microcontrollers. It is a combination of a development manager, simulator debugger, emulator debugger, monitor debugger, and an integrated development environment for efficient development. ■ Purpose of this manual and target readers This manual explains functions of SOFTUNE Workbench. This manual is intended for engineers designing several kinds of

Summary of the content on the page No. 6

• The contents of this document are subject to change without notice. Customers are advised to consult with sales representatives before ordering. � The information, such as descriptions of function and application circuit examples, in this document are presented solely for the purpose of reference to show examples of operations and uses of FUJITSU SEMICONDUCTOR device; FUJITSU SEMICONDUCTOR does not warrant proper operation of the device with respect to use based on such information. When yo

Summary of the content on the page No. 7

READING THIS MANUAL ■ Configuration of Page In each section of this manual, the summary about the section is described certainly, so you can grasp an outline of this manual if only you read these summaries. And the title of upper section is described in lower section, so you can grasp the position where you are reading now. iii

Summary of the content on the page No. 8

iv

Summary of the content on the page No. 9

CONTENTS CHAPTER 1 BASIC FUNCTIONS ..................................................................................... 1 1.1 Workspace Management Function ..................................................................................................... 2 1.2 Project Management Function ............................................................................................................ 3 1.3 Project Dependence .........................................................................
